Bently Nevada 3300 XL 8 mm Proximity Probe (Model: 330103-00-16-10-12-CN)

Product Description

A reliable industrial sensor for vibration monitoring, this 8mm proximity probe from Bently Nevada features durable construction and advanced sealing. Ideal for harsh environments, it delivers precise measurements for critical machinery checks.

Technical Data

Model Suffix Breakdown

330103: Base model – 3300 XL 8mm probe with M10x1 thread (no armor).
00: Unthreaded length – 0mm.
16: Overall case length – 160mm.
10: Total length – 1.0 meter (3.3 feet).
12: Connector type – Miniature coaxial ClickLoc with FluidLoc cable.
CN: Country-specific agency approval.

Key Specifications

Linear Range: 2mm (80 mils), from 0.25mm to 2.3mm (10-90 mils).
Recommended Gap: -9 Vdc (≈1.27mm/50 mils).
Probe Resistance: 7.59Ω ±0.50Ω (1.0m length).
Materials: Tip – Polyphenylene sulfide (PPS); case – AISI 303/304 stainless steel.
Temperature Range:
Standard: -52°C to +177°C (-62°F to +350°F).
Extended (tip): -52°C to +218°C (-62°F to +425°F); cable/connector: -51°C to +260°C (-60°F to +500°F).

Installation Guide

Use 0.2-1.5mm² (16-24 AWG) wiring. Recommended: 3-conductor shielded triad cable with tinned ends. Max field wiring length: 305 meters (1,000 feet).

Compatibility

Works with 3300 XL Proximitor Sensors. Note: Longer wiring may reduce high-frequency signal quality – refer to frequency response graphs for details.

Certifications

Intrinsically Safe (ia): Class I Zone 0 (AEx/Ex ia IIC T5…T1 Ga); Class I Groups A/B/C/D, Class II E/F/G, Class III.
Nonincendive (nA/ec): Class I Zone 2 (AEx/Ex nA/ec IIC T5…T1 Gc); Class I Division 2 Groups A/B/C/D.

Package Includes

1x Probe Unit, 1x Miniature Coaxial ClickLoc Connector (FluidLoc cable), 1x Basic Setup Manual.
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
