Bently Nevada 330104-00-05-10-02-05 3300 XL 8mm Proximity Probe

Product Overview

A rugged industrial sensor for non-contact measurements, this 3300 XL 8mm Proximity Probe from Bently Nevada features a PPS tip and AISI 303/304 stainless steel case. Sealed with a Viton® O-ring for pressure resistance, it’s certified for hazardous areas and built to perform in tough environments.

Model Suffix Explained

Break down 330104-00-05-10-02-05 with these key codes:

• -00: Unthreaded length – 0mm
• -05: Case length – 50mm
• -10: Total cable length – 1.0m (3.3ft)
• -02: Connector – Miniature coaxial ClickLoc (standard cable)
• -05: Approvals – CSA, ATEX, IECEx

Key Technical Specs

Brand: Bently Nevada
Model: 330104-00-05-10-02-05
Type: 3300 XL 8mm Proximity Probe
Probe Resistance: 7.59 ± 0.50Ω (1.0m length)
Output Resistance: 50Ω
Sensitivity: <2mV change per volt input
Power Requirement: -17.5Vdc to -26Vdc (nonincendive); -23Vdc to -26Vdc (with barriers)
Operating Temp (Probe Only): Ranges from -55°C to +232°C (T1) down to -55°C to +40°C (T5), based on rating.

Installation Tips

Install with nonincendive circuits (Drawing 140979) or zener barriers/isolators (Drawing 141092). For best results, gap at 1.27mm (50 mils) using an AISI 4140 steel target.

Compatibility

Works with 3300-series 5mm probes and 3300 XL 8mm extension cables. Accuracy is guaranteed only with AISI 4140 steel targets.

Safety Certifications

Certified for hazardous zones via CSA, ATEX, IECEx. Ratings include Class I Zone 0 (Ga) for gas/dust, Class I Zone 2 (Gc), and more.

What’s Included

3300 XL 8mm Probe, Miniature coaxial ClickLoc connector, 1.0m standard cable.

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
