Bently Nevada 330103-00-05-10-12-00 3300 XL 8mm Proximity Probe

Overview

A compact, high-reliability sensor built for industrial vibration monitoring. Bently Nevada’s 8mm probe excels in tight factory or machinery spaces, with a 1-meter design balancing precision and flexibility.

Model Number: Step-by-Step

Let’s unpack 330103-00-05-10-12-00:

330103: Base 8mm probe (M10x1 thread, no armor)
00: Unthreaded length (0mm – smooth from tip to thread start)
05: Case length (50mm – outer body size)
10: Total probe length (1.0m / 3.3ft – full sensor length)
12: Connector type (mini coaxial ClickLoc + FluidLoc cable – durable, secure connection)
00: No extra safety approvals needed (standard for most setups)

Key Performance Stats

Measure Range: 2mm (80 mils) – works from 0.25mm (10 mils) to 2.3mm (90 mils)
Resistance: 7.59Ω ±0.50Ω (for 1m length – stable signal output)
Temperature: Works from -52°C to +177°C (-62°F to +350°F). Tip handles up to +218°C (+425°F) in extended use.
Cable Limit: Up to 305m (1,000ft) between probe and monitor – flexible for large systems

Built for Durability

Tip: PPS plastic (strong, heat-resistant – won’t warp under stress)
Case: AISI 303/304 stainless steel (rust-proof, long-lasting – stands up to harsh chemicals)
Seal: Viton O-ring (seals pressure between tip and case – prevents leaks)
Weight: 323g/m (11.4oz) – light but sturdy (easy to install in tight spots)

Safety & Compliance

Explosive Areas (ia): Safe for Class I Zone 0 (Groups A-D), Class II (Groups E-G) with zener barriers or isolators.
Non-Explosive Areas (nA/ec): Safe for Class I Zone 2 (Division 2, Groups A-D) with nonincendive circuits.

Install & Use

Use 3-wire shielded cable (0.2-1.5mm² / 16-24 AWG – reduces signal noise).
Tin field wiring (improves connection reliability).
Avoid temps below -34°C (-30°F) (prevents early seal failure).

Works With

Pairs with 3300 XL Proximitor Sensors for full vibration monitoring systems.

What’s in the Box

1x 330103-00-05-10-12-00 proximity probe unit.
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
