GE Fanuc IC695MDL664 RX3i 16-Point Digital Input Module
Product Overview
The IC695MDL664 is a 16-point positive logic input module for RX3i.
It uses 24 V DC field power.
Inputs split into two isolated groups of eight points.
The module works with switches and proximity sensors.
It logs terminal block insertion and removal events.
Technical Specifications
| Feature | Specification |
|---|---|
| Brand | GE Intelligent Platforms / GE Fanuc |
| Series | RX3i PACSystem |
| Part Number | IC695MDL664 |
| Module Type | Positive Logic Input Module |
| Rated Voltage | 24 V DC |
| Number of Inputs | 16 (2 groups of 8) |
| Input Current | 12.2 mA |
| Input Voltage Range | 18–32 V DC |
| Power @ 5 VDC | 225 mA |
| Power @ 3.3 VDC | 95 mA |
| Group-to-Group Isolation | 250 V AC / 1500 V AC |
| LED Indicators | 16 input LEDs; S1 and S2 group LEDs |
| Terminal Block | Supports spring or box style terminal blocks |
Key Features
16 input points in two isolated groups
Rated field voltage: 24 V DC
Low input current: 12.2 mA
Low backplane power draw at 5 V and 3.3 V
Terminal block insertion/removal logging
16 LEDs for quick input status checks
Fits any RX3i input or I/O slot
Works with limit switches and proximity sensors
