IC695ALG628 HART Analog Input Module
| Key Features | |
|---|---|
| Input Channels | 8 single or 4 differential |
| Signal Types | ±10V, 0-10V, 4-20mA, ±20mA |
| HART Support | Version 5.0 (2 internal modems) |
| Resolution | 24-bit ADC |
| Auto Features | Calibration & diagnostics |
| Technical Specifications | |
| Voltage Range | ±10V, 0-10V, ±5V, 0-5V, 1-5V |
| Current Range | 0-20mA, 4-20mA, ±20mA |
| Power | 5V@450mA, 3.3V@600mA |
| Operating Temp | 0°C to 60°C (32°F to 140°F) |
| Filters | 8Hz to 500Hz (6 options) |
| Applications | |
| |
| Package Includes | |
| |
Note: Terminal blocks sold separately. Compatible with RX3i systems.
