IC694MDL340 GE Fanuc RX3i 120 VAC Output Module

GE Fanuc IC694MDL340 — RX3i 16-Point 120 VAC Output Module

Quick overview

Model: IC694MDL340
Outputs: 16 points (2 groups of 8)
Rated voltage: 120 VAC (85–132 VAC range)
Per-point rating: 0.5 A
Group limit: 3.0 A per group
Shelf life before commissioning: 1 year

Key features (simple words)

Each output has an RC snubber.
Each output has its own LED.
Two groups have separate commons.
Module needs user-supplied AC to run loads.
Optical isolation: 250 VAC continuous and 1500 VAC for 1 minute.

Additional numeric details (new, not repeated)

Module size (W × H × D): 34 × 145 × 140 mm.
Unit weight (packed): 270 g.
Typical power dissipation (all outputs ON): ≈ 8 W.
Recommended wire size: 0.75–2.5 mm² (18–14 AWG).
Terminal screw torque: 0.5 N·m.
Conductor strip length (recommended): 7 mm.
Max recommended conductor length to load: 30 m per output circuit to limit EMI.
Operating altitude: 0–2000 m (no derating); above 2000 m derate 1% per 100 m.
Estimated MTBF (typical at 25°C): 100,000 hours.

Electrical performance highlights

On response time (typical): ≤ 1 ms.
Off response time: ≤ 1/2 AC cycle.
Max inrush: 20 A for 1 cycle.
Output voltage drop (max): 1.5 V.
Off-state leakage (max): 2 mA.
Backplane draw (all outputs on): 315 mA.
