GE Fanuc IC693CPU367 Series 90-30 CPU Module — PROFIBUS-DP Slave PLC
Main Specifications
| Parameter | Value |
|---|---|
| Processor | 80386EX |
| Memory | 240 KB |
| Configuration | PROFIBUS-DP Slave |
| I/O Capacity | 4096 discrete points |
| Serial Port | RS-232 |
| Data Rates | 9.6 / 19.2 / 93.75 / 187.5 / 500 kbps, 1.5 / 3 / 6 / 12 Mbps |
| Backplane Current | 940 mA at +5 VDC |
| Floating Point Math | Supported |
| CPU Version | 10.72 or later |
| Operating Temp | 0 to 60 °C (32 to 140 °F) |
| Storage Temp | -40 to 85 °C (-40 to 185 °F) |
Additional Details
Brand: GE Fanuc
Series: Series 90-30
Model: IC693CPU367
Memory Type: RAM and Flash
Network: PROFIBUS-DP slave, supports multiple data rates
Programming: Software version 5.0 or later
Status LEDs: Show network status and alarms
Why Choose IC693CPU367
This CPU connects as a PROFIBUS-DP slave to master devices.
It supports 4096 discrete I/O points and floating-point math.
RS-232 port allows programming and firmware updates.
The 80386EX processor ensures stable, long-term operation.
