IC693CPU350 Series 90-30 Processor Module GE Fanuc

GE Fanuc IC693CPU350 — Series 90-30 PLC CPU Module 25 MHz

Product Introduction

The IC693CPU350 is a single-slot CPU from the Series 90-30 PLC family.

It uses an 80386EX processor with a speed of 25 MHz.

The scan rate is 0.22 ms per 1K Boolean logic.

It includes 32 KB of user memory with RAM and Flash storage.

The module uses the RS-485 port on the power supply for SNP and SNP-X communication.

Key Highlights

Technical Specifications

Discrete inputs: 2048 points

Discrete outputs: 2048 points

Analog inputs: 2048 words

Analog outputs: 512 words

Timers / Counters: More than 2000

Baseplates supported: Up to 8 (1 CPU + 7 I/O)

Serial port: RS-485 via power supply, SNP/SNP-X protocols

Optional networks: Ethernet, FIP, Profibus, GBC, GCM, GCM+

Functions: Shift register, floating point math, interrupts, override

Operating range: 0–60 °C (32–140 °F)
