IC200MDL741 Output Module – GE Fanuc

IC200MDL741 Output Module

The IC200MDL741 is a 16-output module from GE Fanuc. It works with Versamax control systems. This module drives relays, solenoids, and small motors. It provides 0.5A per output point.

Key Features

Power and Protection

The module needs 18-30 VDC external power. It also uses 75 mA from the backplane. The module has strong protection features. It stops short circuits and overloads.

Technical Details

• Output type: Sourcing
• Protection: Short circuit and overcurrent
• LED indicators: Per point, OK, and field power
• Power terminals: A17 (DC+) and A18 (DC-)

Common Questions

What is the output current?

Each output provides 0.5A at 30VDC maximum.

How many output points?

It has 16 output points in one group.

What power does it need?

It needs 18-30 VDC external power and backplane power.

Is it protected?

Yes. It has short circuit and overcurrent protection.

Are modules new?

Yes. We sell only new IC200MDL741 modules.

How fast is shipping?

We ship in 5 days using DHL and FedEx.

Can I return it?

Yes. Return within 30 days if unused in original packaging.
