IC200MDD848 GE Fanuc – Mixed I/O Module

GE Fanuc IC200MDD848 Mixed I/O Module

Main Features

• 16 total points (8 in, 8 out)
• High current outputs – 5 Amps
• Built-in protection circuits
• Grouped wiring – 2 groups of 8
• Status LEDs for all points

Technical Details

Input Information

The module has 8 input points. They use positive logic type wiring. This means they can read signals from field devices.

Each input has a status LED light. The LED shows when the input is active. This helps with troubleshooting.

Output Information

The module has 8 output points. Each output can handle high current up to 5.0 Amps. Outputs have channel-to-channel isolation.

Built-in protection includes MOVs and snubbers. These protect against voltage spikes. For inductive loads, extra suppression is recommended.

Power Requirements

The module needs 5 volt DC from the backplane. It uses 125 milliamps of current. An external 120 VAC power source is needed for loads.

The module supports thermal derating. This means it reduces power when temperatures rise. This protects the module from damage.

Questions and Answers

How many points does it have?

It has 16 points total. There are 8 inputs and 8 outputs in two groups.

What is the maximum current?

Outputs can handle 5.0 Amps maximum. The minimum current is 10 milliamps.

What protection does it have?

It has MOVs and snubbers built in. These protect against electrical noise and spikes.

Is it in stock?

Yes, we have the IC200MDD848 in stock. All units are new and original.

What external power is needed?

Loads need 120 VAC external power. The module itself uses 5 VDC from backplane.

When do you ship?

We ship within 5 business days. We use reliable carriers like DHL and FedEx.

Can I return it?

Yes, returns are accepted within 30 days. The item must be in original condition.
