I/O Module GE Fanuc IC694MDR390

GE Fanuc IC694MDR390 RX3i PacSystem Mixed I/O Module

Technical Specifications

• Brand: GE Fanuc
• Series: RX3i PacSystem
• Part Number: IC694MDR390
• Module Type: Mixed Input/Output
• Operating Voltage: 5–30 V DC / 5–250 V AC
• Switching Current: 2.0 Amps
• I/O Capacity: 8 Isolated Inputs / 8 Outputs
• Isolation: 500 V AC RMS between points
• Max Backplane Draw: 6 mA at 5 V DC
• Inrush Rating: 5.0 Amps
• Max Response Time: 15 ms
• Groups: 1 Input Group, 2 Output Groups
• LED Indicators: 16 LEDs
• Installation: RX3i I/O backplane slot

Key Features

• Supports sinking and sourcing inputs for flexible connections.
• Relay outputs handle high-current field devices safely.
• Fast response time for both inputs and outputs.
• LEDs show clear on/off status for all points.
• Works with switches, pushbuttons, solenoids, and motor starters.
