GE Fanuc IC693CBK002 Series 90-30 High-Density TBQC Cable Kit
Product Overview
The IC693CBK002 cable kit is for Series 90-30 PLC high-density modules.
It contains two cables for left and right ends.
The kit is designed for 32-point I/O modules using TBQC assemblies.
Each cable has a 24-pin connector on one end and stripped wires on the other.
Right-angle connectors extend 2 inches from the module face.
Each conductor supports 1.2 Amps safely.
Cable length is 1 meter per cable.
This kit is ideal for reducing front clearance space in PLC installations.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | GE Fanuc |
| Series | Series 90-30 |
| Part Number | IC693CBK002 |
| Type | Cable Kit |
| Function | High-density cables for TBQC assemblies |
| Cables Included | Two (Right and Left) |
| Connector | Fujitsu FCN-365S024-AU, 24-pin |
| Connector Type | Right-angle / stripped wire ends |
| Amperage Rating | 1.2 Amps per conductor |
| Length | 1 meter |
| Kits per Module | 1 (two cables) |
| Compatibility | 32-point I/O modules with TBQC assemblies |
Key Features
High-density cables for safe TBQC module connections.
Right-angle connectors save front space on PLC modules.
Pin-to-pin wiring supports 1.2 Amps per conductor.
