GE Fanuc IC695PBS301 Slave Module

GE Fanuc IC695PBS301 RX3i PROFIBUS Slave Module

Product Overview

The IC695PBS301 is a PROFIBUS Slave module in the RX3i PacSystems series.

It provides reliable communication over the PROFIBUS DP network.

The module includes LED indicators for MOD status, network, and PROFIBUS OK.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: RX3i PacSystems

Part Number: IC695PBS301

Module Type: PROFIBUS Slave Module

Backplane Support: Universal RX3i PCI

Slots: 1 (single slot)

Ports: 9-pin connector

Power Consumption: 440 mA @ 3.3 VDC

Operating Temperature: 0 to 60°C

Storage Temperature: -40 to 85°C

Data Exchange: 244 Bytes input / 244 Bytes output per transaction
