GE Fanuc IC695CNM001 CANopen Master Module

GE Fanuc IC695CNM001 RX3i CANopen Master Module – PacSystems

Product Overview

The IC695CNM001 is a CANopen master module for RX3i systems by GE Fanuc.

It controls up to 5 slave devices on a CANopen network.

The module connects to RX3i CPUs to send and receive data quickly.

It has a USB Mini Type B port and a 9-pin D-connector for setup.

Three LEDs show module status: POWER, MOD Status, NET Status.

The IC695CNM001 supports hot-swapping for easy installation.

Technical Specifications

• Brand: GE Fanuc
• Series: RX3i PacSystem
• Part Number: IC695CNM001
• Module Type: CANopen Master
• Backplane Current: 800 mA at 3.3 VDC
• Slave Devices: 5
• Baud Rate: 10 kbit to 1 Mbit
• Data Layer: CAN Frame, 11 Bit
• TX PDO Scan: up to 272 bytes
• RX PDO Scan: up to 272 bytes
• PDO Mapping, Node Guarding, Lifeguarding: Supported
• Transmit PDOs: 15
• Receive PDOs: 30
• Sync Object: 1
• Rack Slot: Any main rack slot except 0 or expansion
• Required Firmware: RXi3 CPU v7.70+

Features

• Hot-swappable module for easy maintenance
• USB port allows quick network setup
• Heartbeat protocol ensures reliable communication
• Compact design fits RX3i main rack
• LEDs provide clear real-time status
