GE Fanuc IC694MDL310 120 VAC Output Module

GE Fanuc IC694MDL310 — 120 VAC, 12-Point Output Module

At-a-glance (summary)

Model: IC694MDL310

Rated voltage: 120 Volts AC

Outputs: 12 points (2 groups of 6)

Per-point rating: 0.5 A maximum per output

Supply range: 85–132 VAC, 50/60 Hz

Detailed specifications

Key electrical and timing data (additional numeric details):

Minimum load current: 50 mA.

Output voltage drop: 1.5 V maximum.

Output leakage current: 3 mA maximum at 120 VAC.

On response time: ≤ 1 ms.

Off response time: ≤ 1/2 AC cycle.

Inrush capability: 5 A maximum for one cycle (to accommodate inductive/incandescent loads).

Group current limits (ambient temperature dependent): 2.0 A per group at 50°C; 1.0 A per group at 60°C (see wiring diagram for derating curve).

Fusing: Two group fuses (3 A each) protecting the two common groups.

Isolation ratings (safety margins):

Field to backplane: 250 VAC continuous; 1500 VAC for 1 minute.

Group-to-group: 250 VAC continuous; 1500 VAC for 1 minute.

Mechanical & environmental

Module footprint (typical): 34 x 145 x 140 mm (W × H × D).

Operating temperature: 0°C to 60°C.

Storage temperature: -40°C to 70°C.

Relative humidity: 5% to 95% non-condensing.

Power drawn from backplane (all outputs ON): 210 mA from the 5 V bus.
