GE Fanuc IC694ACC300 Input Simulator Module

GE Fanuc IC694ACC300 RX3i Input Simulator Module

Product Overview

The IC694ACC300 simulates 8-point or 16-point input module functions.

It has no field connections but can test and debug systems effectively.

The module is compatible with all RX3i CPUs and industrial systems.

It is hot swap-compatible when installed or removed correctly.

Ensure proper latch engagement and pin connection within 2 seconds.

Never leave the module partially inserted to avoid errors.

Maximum load is 120 mA and 0.6 W at 5 V DC.

Key Features

Manufacturer: GE Fanuc

Series: RX3i PacSystems

Part Number: IC694ACC300

Product Type: Input Simulator Module

Simulations: 8-point and 16-point input functions

Field Connections: None

Compatible CPUs: All RX3i CPUs

Load: 120 mA, 0.6 W at 5 V DC

Hot Swapping: Supported with correct insertion/removal
