GE Fanuc IC693MDL641 I/O Module

GE Fanuc IC693MDL641 Series 90-30 16-Point Negative Logic Input Module

Module Overview

The IC693MDL641 is a 16-point input module for Series 90-30 PLCs.

It operates with negative logic and a rated voltage of 24 VDC.

All inputs share one common power terminal. Users must supply the power to the module.

The module connects external devices such as sensors, buttons, and contactors to the PLC.

Isolation is 1500 Volts RMS between field and logic sides.

Response time is 7 ms typical. LEDs indicate ON/OFF status for each input.

Key Features

16 discrete input points

Negative logic operation

Rated voltage: 24 VDC

Input voltage range: 0–30 VDC

On-state voltage: 15–30 VDC

Off-state voltage: -30–5 VDC

On-state current: 4 mA minimum

Off-state current: 1.5 mA maximum

Power consumption: 5–120 VDC

Response time: 7 ms

16 LEDs show input status

Isolation: 1500 Volts RMS
