GE Fanuc IC693MDL634 Series 90-30 24 VDC Input Module
Product Overview
The IC693MDL634 is an 8-point input module for Series 90-30 PLCs.
It works with positive and negative logic at 24 VDC.
The module has one group of 8 inputs and a single common power terminal.
LED indicators show ON/OFF status for each input.
Key Specifications
| Parameter | Value |
|---|---|
| Brand | GE Fanuc / GE Intelligent Platforms |
| Series | Series 90-30 |
| Part Number | IC693MDL634 |
| Input Channels | 8 points |
| Rated Voltage | 24 VDC |
| Input Voltage Range | 0 to 30 VDC |
| Isolation Field to Logic | 1500 V |
| Typical Input Current | 7 mA |
| On-State Voltage | 11.5 to 30 VDC |
| Off-State Voltage | 0 to 5 VDC |
| On-State Current | 3.2 mA min. |
| Off-State Current | 1.1 mA max. |
Applications
Machine I/O integration
PLC input expansion
Pushbuttons and limit switches
Electronic DC input devices
