GE Fanuc IC693MDL260 — Series 90-30 32-Point Grouped 120VAC Input Module

Product Introduction

IC693MDL260 by GE Intelligent Platforms handles grouped AC inputs for Series 90-30.

The module provides 32 isolated inputs organized into four groups.

The device runs on 120 V AC nominal voltage.

Operators install the module in any input or output slot.

Use common terminal styles for flexible field wiring.

Front LEDs show each channel status at a glance.

Operators set input filter times via the rear DIP switch.

Technical Specifications

Brand: GE Intelligent Platforms / GE Fanuc

Series: Series 90-30

Part Number: IC693MDL260

Module Type: Grouped isolated AC input module

Voltage: 120 V AC nominal; 0–132 V AC range

Frequency: 50/60 Hz standard; 47–63 Hz range

Inputs: 32 points arranged in four groups of eight

Input Current at Rated Voltage: 12 mA

LED Indicators: 32 channel LEDs plus TB status LED

Isolation: Group-level isolation with a shared common connection
