GE Fanuc IC693MDL240 Input Module

GE Fanuc IC693MDL240 AC Discrete Input Module – Series 90-30

Product Overview

The GE Fanuc IC693MDL240 is a discrete input module for AC signals.

It belongs to the Series 90-30 PLC family.

The module has 16 input channels in one group.

It works at 0-132 VAC with nominal voltage 120 V AC.

Technical Specifications

Number of Channels: 16

Input Voltage Range: 0-132 VAC

Nominal Voltage: 120 V AC

Input Frequency: 50/60 Hz

Input Current: 12 mA per channel

Backplane Current Draw: 90 mA

On State Voltage: 74-132 VAC

Off State Voltage: 0-20 VAC

On State Current: 6 mA

Off State Current: 2.2 mA

Isolation: 1500 V RMS

LED Indicators: 16

On Response Time: 30 ms typical

Off Response Time: 45 ms max
