GE Fanuc IC693CPU341 — Series 90-30 20 MHz CPU Module

Product Introduction

The IC693CPU341 is a single-slot CPU for Series 90-30 PLCs.

It runs on an 80C188XL processor at 20 MHz.

The CPU executes Boolean logic in 0.3 ms per 1K contacts.

It comes with 80 KB of program memory and 9999 words of register memory.

The module supports SNP and SNP-X protocols via the power supply serial port.

Key Highlights

Technical Specifications

Discrete inputs: 512 points

Discrete outputs: 512 points

Analog inputs: 1024 words

Analog outputs: 256 words

Timers / Counters: More than 2000

Expansion: Supports up to 5 baseplates (1 CPU + 4 I/O)

Serial ports: 1 port, SNP and SNP-X protocols

Optional networks: Ethernet, FIP, Profibus, GBC, GCM, GCM+

Functions: Shift register, interrupts, override

Operating range: 0–60 °C (32–140 °F)
