GE Fanuc IC660EBS103 Electronic Assembly

GE Intelligent Platforms IC660EBS103 Genius I/O PCI Interface Card

Core Technical Specifications

• Brand & Model: Manufactured by GE, this IC660EBS103 belongs to the Genius I/O series.
• Electrical Ratings: The card supports a wide 4-source voltage range from 93 to 132 Volts AC or 105 to 132 Volts DC.
• Frequency & Power: It requires a frequency of 47 to 63 Hertz and a maximum control power of 8 Watts.
• Isolation & Protection: It features a high 1500 Volts block-to-block isolation rating for safety.
• Environmental Tolerance: It operates reliably in temperatures from 0 to 60°C and withstands 5-95% non-condensing humidity.
• Response & Filtering: Users can select an input filter time between 10 to 100 milliseconds in 10ms steps.

Product Features and Design

• I/O Configuration: This Genius block is highly flexible. You can configure it as input-only, output-only, or a combination block.
• Visual Diagnostics: Each circuit has a dedicated LED. Inputs show threshold status, while outputs display the CPU command state.
• Thermal Performance: The unit manages heat dissipation up to 16.8W (8 inputs) and 45.6W maximum with 8 outputs at 2 Amps.
• Physical Build: The card measures 8.83 x 3.50 x 3.94 inches and has a solid weight of approximately 1.8 kg (4 lbs).
• Default Setting: Every new IC660EBS103 block shis pre-configured as an input-only device for ease of setup.

Frequently Asked Questions (FAQ)

• Q: Is this item in stock?
  A: Yes, we have this IC660EBS103 interface card in ready stock.
• Q: What is the operating voltage range?
  A: It accepts 93-132V AC or 105-132V DC, offering great flexibility for various panels.
• Q: How soon will my order ship?
  A: We process and ship orders within 5 business days after confirmation.
• Q: Can I use this for both inputs and outputs?
  A: Absolutely. The GE Genius IC660EBS103 is configurable as input-only, output-only, or a mixed I/O block.
• Q: What is the isolation rating?
  A: The block provides 1500V of isolation for enhanced safety and noise immunity.
• Q: What is your return policy?
  A: We support a 30-day return policy for your peace of mind. Please contact our team for details.
