GE Fanuc IC660EBR101 Electronic Assembly

GE Fanuc IC660EBR101 Genius Electronic Assembly

The GE Intelligent Platforms IC660EBR101 is a relay output electronic assembly for the Genius I/O system. Specifically, it provides flexible and isolated switching for industrial control applications. Furthermore, it is designed to work with complementary relay output blocks for complete system solutions.

Product Overview & Core Specifications

• Brand: GE Fanuc
• Model: IC660EBR101
• Series: Genius I/O Block Series
• Product Type: Electronic Assembly (Relay Output)
• Output Configuration: 16 output circuits organized in 4 individual groups.
• Output Rating: 2 Amps maximum per circuit.
• Switching Power: Maximum 60 Watts or 125 VA per output.
• Output Voltage: Supports 5-250 V AC or 5-220 V DC operation.
• Relay Type: Fixed coil moving armature design.
• Weight: Approximately 4 pounds.

Electrical & Functional Specifications

• Input Power: 115 V AC (93-132V) or 230 V AC (185-265V) selectable.
• Power Consumption: Typically requires 87 mA at 115 V AC.
• Frequency: Operates at 47 to 63 Hz.
• Group Isolation: Rated for 1500 Volts isolation between groups.
• Minimum Load: For reliable operation, a 10 mA load is recommended.
• Power Supply Hold-up: Features a dropout time of 1 cycle.

Features & Compatibility

• Status Indication: Includes both a block status LED and individual LEDs for each relay coil state.
• Configurable Features: Supports output power-up defaults and “hold last state” functions.
• Compatible Blocks: Works with the IC660BBR100 (NC relays) and IC660BBR101 (NO relays) output blocks.
• System Compatibility: Versatile and compatible with all Genius I/O devices, including QBIM and PCIM modules.
• Typical Loads: Well-suited for controlling contactors, lamps, and other indicator devices.

Frequently Asked Questions (FAQ)

• How many output groups does this assembly have?
  Specifically, its 16 outputs are divided into 4 electrically isolated groups for safe and flexible wiring.
• What is the maximum switching current?
  Consequently, each output circuit can handle up to 2 Amps continuously.
• What relay blocks does it work with?
  It is designed to operate with the IC660BBR100 and IC660BBR101 terminal blocks.
