GE Fanuc IC660BBS102 I/O Block

GE Fanuc IC660BBS102 Genius I/O Block

Key Specifications

• Brand: GE Fanuc
• Model: IC660BBS102
• Voltage: 115 VAC / 125 VDC
• Circuits: 8 circuits in 4 isolated groups
• Isolation: 250 VAC between groups
• Protection: 2000V peak for 10 seconds
• Response Time: AC: 2ms + filter, DC: 0.8ms + filter
• Current Rating: 2A AC, 2A DC resistive
• Temperature Safety: Shuts down above 100°C
• Size: 8.8 x 3.3 x 3.9 inches
• Weight: 4 pounds
• Heat Output: 45.6 Watts maximum

Main Features

• Failed switch diagnostics for safety
• Overload and no-load detection
• Short circuit protection in 5 microseconds
• Temperature protection at 100°C
• Open wire detection
• Selectable filter times: 10ms to 100ms
• Output pulse testing
• Works with CPU redundancy systems

Installation Guide

• Use protective enclosures only
• Keep area clean and dry
• Allow 2 inches space between blocks
• Mount right-side up or upside down
• Ensure proper cooling airflow
• Use separate ground wire
• Terminals fit #12 AWG or two #14 AWG wires
• Use 6 inches/lb torque on terminals

FAQ

• What power does it use?
  It uses 115V AC or 125V DC power.
• How many circuits does it have?
  It has eight circuits in four isolated groups.
• What protection does it offer?
  It has short circuit, overload, and temperature protection.
• Is this unit new?
  Yes, we sell only new, genuine units.
• How fast do you ship?
  We ship in 5 days via DHL, FedEx, or UPS.
• What is your return policy?
  We accept returns within 30 days.
