GE Fanuc IC660BBR101 Relay Output Block

GE Fanuc IC660BBR101 Relay Output Block

Technical Specifications

• Brand: GE Fanuc
• Model: IC660BBR101
• Series: Genius I/O
• Contact Type: Normally Open
• Number of Outputs: 16 outputs
• Output Groups: 4 groups of 4 outputs
• Voltage Range: 5-250 VAC or 5-220 VDC
• Load Current: 2 Amps maximum
• Isolation: 1500 VAC between groups
• Operating Frequency: 47-63 Hz

Key Features

• Normally open relay design
• Fixed coil and moving armature type
• Four isolated output groups
• Works with AC or DC power
• LED status indicators
• Supports CPU redundancy
• Bus switching module capability
• Easy voltage selection via jumpers

Operating Conditions

• Work Temperature: 32°F to 140°F (0°C to 60°C)
• Storage Temperature: -40°F to 212°F (-40°C to 100°C)
• Humidity: 5-95% non-condensing
• Operating Voltage: 93-132 VAC or 185-265 VAC
• Group Isolation: 1500 VAC rated
• Relay Type: Fixed coil, moving armature

FAQ

• What does normally open mean?
  Contacts stay open until power is applied to close them.
• How many outputs does it have?
  It has 16 relay outputs in four groups.
• What is the maximum current?
  Each output handles up to 2 Amps.
• Can I change the voltage?
  Yes, use jumpers for 115V or 230V selection.
• What relay type is used?
  Fixed coil with moving armature design.
• Is there a normally closed version?
  Yes, consider model IC660BBR100.
