GE Fanuc IC200MDD851 – Mixed I/O Module

GE Fanuc IC200MDD851 Discrete I/O Module

Main Features

• 16 output points total
• Two groups of eight outputs
• Works with positive or negative logic
• LED status lights
• External power for loads

Technical Details

Logic Types

The module works with positive and negative logic. Positive logic inputs take current from devices. Negative logic inputs work the opposite way.

Use negative logic for TTL devices. This gives you more connection options. You can choose the best logic type for your devices.

Output Information

All 16 points are output points. They use sourcing or positive logic type. Outputs switch loads to positive DC power.

Outputs provide current to connected loads. They are grouped in two sets of eight. This makes wiring easier to manage.

Power and Indicators

The module gets power from the backplane. Output loads need external power. A CPU or NIU handles the processing.

LED lights show each point’s status. A green power LED shows field power is on. The lights help find problems quickly.

Questions and Answers

How many points does it have?

The IC200MDD851 has 16 output points total. They are in two groups of eight.

What logic types does it support?

It works with both positive and negative logic. This gives you more flexibility.

What powers the output loads?

Output loads need external power. The module itself uses backplane power.

Is it in stock?

Yes, we have the IC200MDD851 in stock. All units are new and original.

What processing does it need?

It needs a CPU or Network Interface Unit. This handles the smart processing.
