GE Fanuc IC200ALG321 Output Module

GE Fanuc IC200ALG321 Analog Output Module

The IC200ALG321 controls voltage signals. It has 4 output channels. Sends 0-10 VDC signals. Made by GE Fanuc, now Emerson.

Product Details

• Brand: GE Fanuc
• Model: IC200ALG321
• Series: VersaMax
• Channels: 4 outputs
• Voltage Output: 0-10 VDC
• Resolution: 12-bit
• Update Speed: 0.3 ms
• External Power: 18-30 VDC needed
• Accuracy: 0.3% typical
• Status Lights: 2 LEDs
• Backplane Power: 50 mA max

Technical Specifications Table

• Output Type: Voltage
• Signal Range: 0-10 VDC
• Resolution: 12 bits (2.5 mV)
• Update Rate: 0.3 ms maximum
• External Power: 18-30 VDC / 9.6-15 VDC
• Current Draw: 210 mA maximum
• Isolation: 250VAC continuous
• Load Requirement: 5000 Ohms minimum
• Operating Temp: 0-60°C
• Wiring: Single-ended

Main Features

• Controls 0-10 VDC signals
• Fast 0.3 ms updates
• Good 12-bit resolution
• Two status lights
• Finds power problems
• Holds last state
• Safe isolation
• Easy wiring

How to Install

• Mount on VersaMax rack
• Connect external power
• Wire 4 outputs
• Check both lights
• Use setup software
• Set fault actions
• Test all channels

Safety Protection

• Finds power loss
• Holds last values
• Safe electrical isolation
• Works in tough places
• Checks field power
• Shows faults quickly
• Stops signal jumps

Questions Answered

• Output type? 0-10 VDC
• How many channels? 4
• Need extra power? Yes
• Resolution? 12-bit
• Update speed? 0.3 ms
• Status lights? 2 LEDs
• Fault protection? Yes
