GE Fanuc IC200ALG261 Analog Input Module

GE Fanuc VersaMax IC200ALG261 Analog Input Module

The IC200ALG261 from GE Fanuc works with VersaMax PLC systems. This module has 8 differential inputs for factory machines.

Key Features

• Brand: GE Fanuc
• Series: VersaMax
• Model: IC200ALG261
• Type: Analog Input Module
• Channels: 8 differential inputs
• Power: Backplane power
• Current Use: 200 mA at 5V
• Isolation: 250V AC continuous
• LED: 1 green “OK” light

Power Supply

• Gets power from the PLC backplane
• No extra power needed for normal use
• Uses 200 mA from backplane
• Extra power needed for transceivers
• Green light shows power is working

Input Channels

• Has 8 differential input channels
• Connects to 8 analog devices
• Works with PLC CPU for smart control
• No isolation between channels
• Reports power loss problems

Status Lights

• Green “OK” light shows status
• Light means backplane power is on
• Shows internal power works right
• Indicates good module setup
• Confirms backplane sees the module

Installation Guide

• Fits in VersaMax PLC systems
• No external power usually needed
• Works with PLC CPU
• Watch green LED for status
• Add power for transceivers

Common Questions

• How is it powered?
  From the VersaMax PLC backplane.
• What does the green light mean?
  Power is good and module works.
• How many inputs?
  8 differential input channels.
• Needs extra power?
  Only for transceiver devices.
• Channel isolation?
  No, but has input to logic isolation.
