Flexem FPad916R001 Industrial HMI

Flexem FPad916R001: Advanced IoT HMI for Demanding Applications

Display & Touch Interface

• The FPad916R001 features a crisp 15.6-inch TFT LCD with 1920×1080 Full HD resolution.
• It provides consistent 85°/85°/85°/85° viewing angles for clear visibility.
• The screen displays 24-bit color at 250 cd/m² brightness with an LED backlight.
• User input is via a rugged 4-wire industrial resistive touch panel.

Core Processing Hardware

• Powered by an Intel Celeron J3455 quad-core CPU (1.5GHz base, up to 2.3GHz).
• The system includes 8GB of DDR3L RAM for handling multiple applications.
• It offers a substantial 128GB SATA SSD for fast and reliable storage.
• A built-in Real-Time Clock (RTC) maintains accurate system time.

Complete Technical Specifications

• Brand & Model: Flexem FPad916R001
• CPU: Intel Celeron J3455 Quad-core, 1.5-2.3GHz
• Memory: 8GB DDR3L
• Storage: 128GB SATA SSD
• Communication Ports:
  • Ethernet: 2 x Gigabit RJ45 (10/100/1000Mbps)
  • USB: 4 x USB 3.0 Type-A (Rear)
  • Serial: COM1 (RS232/485/422), COM2 (RS485/422), COM3 (RS232)
  • Display: 2 x HDMI (supports up to 3840×2160@30Hz)
  • Optional: WiFi Module
  • Note: RS485 via USB converter is supported
• Software & OS:
  • Programming: FStudio Unified
  • Operating System: Linux
• Power Specifications:
  • Input: DC 12V (< 5A)
  • Rated Power: < 60W
  • Interruption Tolerance: < 5ms
  • Protection: Isolated adapter with surge protection
• Environmental Ratings:
  • Operating Temperature: 0°C to 50°C
  • Storage Temperature: -20°C to 60°C
  • Humidity: 10-90% RH (Non-condensing)
  • Front Protection: IP65 / NEMA Panel
  • Vibration: 10-25Hz, 2G, 30min (X,Y,Z directions)
• Physical Dimensions:
  • Cutout: 380 x 245 mm
  • Dimensions: 394 x 256 x 53.3 mm
  • Weight: ~2950g
  • Housing: Non-ferrous Alloy
  • Cooling: Natural Convection
  • Installation: Flush-mounted
• Certifications: CE, RoHS

Frequently Asked Questions (FAQ)

• Q: What is the main advantage of the FPad916R001’s processor?
  A: The Intel Celeron J3455 CPU provides robust x86 processing power for data-intensive applications, outperforming typical ARM-based HMIs.
• Q: Can I expand the storage capacity?
  A: The built-in 128GB SSD is fixed, but external storage can be added via the USB 3.0 ports.
• Q: What is the minimum operating temperature?
  A: The panel operates from 0°C, making it suitable for controlled industrial environments.
• Q: How many displays can I connect?
  A> You can connect up to two external displays simultaneously using the dual HDMI ports.
• Q: What software is needed for programming?
  A: Use Flexem’s FStudio Unified software to develop and deploy applications.
