FC5-30MN-DC Flexem Controller -18 Input 12 Output

Flexem FC5-30MN-DC Programmable Logic Controller

Main Technical Specifications

• Brand & Model: This unit is the Flexem FC5-30MN-DC.
• Power Supply: It requires 24V DC power.
• Built-in I/O: It provides 30 total I/O points. This includes 18 inputs and 12 NPN transistor outputs.
• Expansion Slot: You can add 1 expansion board for extra functions.
• Communication Ports: It offers multiple ways to connect.
• 1 Ethernet port (RJ45, 10/100M) for network setup.
• 2 serial ports (RS485/RS232) for Modbus networks.
• 1 USB Type-C port for easy programming.
• Real-Time Clock: Built-in clock with battery keeps time for one year if power fails. Accuracy is about ±3 seconds per day.

Setup and Installation Notes

• Install the controller on a DIN rail inside an electrical cabinet.
• Ensure the environment is within operating temperature and humidity limits.
• Connect the 24V DC power supply with correct polarity.
• Use shielded cables for communication ports to prevent signal issues.

Package Contents & Delivery

• What’s in the Box:
• One FC5-30MN-DC controller unit.
• Installation and user documentation.
• All items are new and in original factory packaging.
• Orders ship within 5 working days after confirmation.
• We ship worldwide using DHL, FedEx, or UPS.

Frequently Asked Questions (FAQ)

• Q: What does “MN” mean in the model name?
• A: The “MN” indicates NPN transistor outputs. This model has 12 of them.
• Q: How can I expand this system?
• A: You can connect 1 expansion board to add more I/O or special functions.
• Q: Does it keep time during a power outage?
• A: Yes. The built-in real-time clock has a battery that lasts about one year without main power.
• Q: What networks can it communicate on?
• A: It works on standard Ethernet networks and supports Modbus via its serial ports.
• Q: What is your return policy?
• A: We accept returns within 30 days for items that are new and unused.
