Extension Cable – Bently Nevada | 330130-085-02-CN

Bently Nevada 330130-085-02-CN Extension Cable Overview

This extension cable, designed by Bently Nevada, connects 3300 XL 8 mm probes to monitoring systems for industrial machinery. With an 8.5m length, it ensures reliable signal transmission in harsh environments. Each unit includes silicone tape for quick fixes, though turbine oil exposure is not recommended. Its robust build, including patented CableLoc technology, boosts durability for long-term use.

Technical Specifications

• Brand: Bently Nevada (trusted industrial sensor solutions)
• Model: 330130-085-02-CN (full compatibility with 3300 XL 8 mm systems)
• Model Suffix Breakdown:
  – “085”: 8.5 meters (27.9 ft) cable length
  – “02”: Standard cable with connector protector
  – “CN”: Country-specific approval
• Length: 8.5m (27.9 ft)
• Weight:
  – Standard: 34g/m (0.4 oz/ft), total 0.289kg
  – Armored: 103g/m (1.5 oz/ft), total 0.875kg
• DC Resistance:
  – Center conductor (RCORE): 1.87±0.28Ω (8.5m)
  – Outer conductor (RJACKET): 0.56±0.11Ω (8.5m)
• Capacitance: 69.9pF/m (21.3pF/ft) typical
• Power Requirement: -17.5Vdc to -26Vdc (12mA max); -23Vdc to -26Vdc with barriers
• Sensitivity: <2mV output change per 1V input shift
• Output Resistance: 50Ω
• Field Wiring: 0.2-1.5mm² (16-24 AWG); max 305m (1,000ft) to monitor
• Linear Range: 2mm (0.25-2.3mm gap from target)
• Humidity Performance: <3% ASF change at 93% humidity (56 days, IEC 68-2-3)
• Probe Strength: 330N (75 lbf) pull strength via patented CableLoc design

Note: Silicone tape included, but avoid for turbine oil-exposed connections. Probes use Viton® O-rings for pressure sealing (not pre-tested; contact for custom tests).

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
