Bently Nevada | Housing Assembly | 24701-28-10-00-090-03-02

Industrial Vibration Monitoring Solution

Advanced Protection for Machinery

This factory-sealed Bently Nevada assembly features 9-inch probe penetration with comprehensive fitting kit. Designed for precision vibration measurement in critical industrial applications.

Complete Product Identification

• Manufacturer: Bently Nevada
• Full Part Number: 24701-28-10-00-090-03-02
• Configuration: 3300 XL 8mm probe with connector
• Penetration Depth: 9 in (229 mm)

Key Performance Specifications

• Operating Range: -40°F to 250°F (-40°C to 121°C)
• Output Signal: -18V to -26V DC
• Accuracy: ±1.2% full scale
• Response Time: <5 ms
• Body Material: 303 Stainless Steel
• Sleeve Material: 304 Stainless Steel
• Mounting Thread: 3/4-14 NPT
• Cable Length: 1 m (39 in)

Included Fittings Kit

• 1 × 3/4-14 NPT plug
• 1 × 3/4-14 to 1/2-14 NPT reducer
• Cable seal grip with grommets for:
  • 1/8 to 3/16 in cables
  • 1/4 to 5/16 in cables
  • 5/16 to 3/8 in cables

Simple 4-Step Installation

1. Mount housing using 3/4-14 NPT threads
2. Insert probe to 9-inch depth marker
3. Select appropriate cable grommet
4. Secure with included fittings

Compatibility & Integration

Direct plug-and-play with Bently Nevada 3300 series monitoring systems. Compatible with most industrial vibration analysis platforms.

Safety Certifications

• ATEX Zone 2 certified
• IECEx compliant
• IP66 environmental rating
• Hazardous location approved

Industrial Application Examples

• Power generation turbine monitoring
• Oil refinery compressor protection
• Chemical plant pump diagnostics
• Paper mill gearbox analysis

Quality Assurance

Full 12-month manufacturer warranty against defects. Ships in original protective packaging with all components sealed.

Download PDF file here:21000-24701-Datasheet
