Bently Nevada 3300 NSv Long Probe – 330905-00-25-05-02-05
Product Highlights
The 330905-00-25-05-02-05 features a 250mm long case with 0.5m cable. Perfect for deep installations in pumps and compressors. Works in extreme cold and heat (-52°C to +177°C).
Key Features
- Extra-long 250mm case for deep mounting
- Short 0.5m cable with ClickLoc connector
- M10X1 thread (no armor)
- Chemical-resistant PPS tip
- Stainless steel body
Technical Specs
Measurement Range: 0.25–1.75mm (10–70 mils)
Output: -1 to -13 Vdc
Accuracy: ±0.06mm (±2.3 mils)
Temp Range: -52°C to +177°C
Cable Bend Radius: >25.4mm
Part Number Breakdown
- 330905 – Base model
- -00 – Standard length
- -25 – 250mm long case
- -05 – 0.5m cable
- -02 – ClickLoc connector
- -05 – Certified design
Installation Notes
- Set gap to 1.0mm (40 mils)
- Hand tighten only (max 0.56 N•m)
- Works best on shafts >13mm diameter
Where To Use
Ideal for deep well pumps, large compressors, and applications needing long probe reach.
Download PDF file here:3300 XL NSv Proximity Transducer System Datasheet – 147385
