Bently Nevada 3300 XL 11mm Proximity Probe – Model 330703-010-075-10-01-00
Quick Overview
A brand-new, factory-sealed proximity probe from Bently Nevada, designed for precise industrial machinery monitoring. Built with a 11mm probe tip, it’s reliable in tough conditions and backed by a 12-month factory warranty.
Full Model Breakdown
Brand: Bently Nevada
Model: 330703-010-075-10-01-00 (detailed suffixes):
010: 10mm unthreaded length
075: 75.0mm overall case length
10: 1.0m total cable (3.3ft)
01: Miniature coaxial ClickLoc connector (with protector)
00: No specific agency approval required
Key Technical Features
DC Resistance: 5.9 ± 0.5 ohms (1.0m cable)
Magnetic Field Impact (60Hz, up to 300 Gauss):
0.5mm gap: 0.001 mil pp/gauss
2.5mm gap: 0.009 mil pp/gauss
4.6mm gap: 0.027 mil pp/gauss
Materials:
Tip: Polyphenylene sulfide (PPS)
Case: AISI 304 stainless steel
Cable: 75Ω triaxial with FEP insulation (1m/5m/9m options)
Temperature & Durability
Operating/Storage Range: -52°C to +177°C (-62°F to +351°F)
Caution: Below -34°C (-30°F) may damage the pressure seal.
Temperature Classes:
EPL Ga/Gc: T1 (-55°C to +232°C) to T5 (-55°C to +40°C)
EPL Dc: T280°C (at -55°C to +232°C) to T90°C (at -55°C to +40°C)
Installation Guide
Max Torque: 63.3 N•m (560 in•lb)
Recommended Torque: 21.1 N•m (187 in•lb)
Thread Engagement: M14x1.5, max 21mm
What’s Included
1x 330703-010-075-10-01-00 probe
Connector protector
User manual
Warranty certificate
Where It Shines
Perfect for monitoring:
Turbines (up to 12,000 RPM)
Pumps in chemical plants
Compressors in power stations
Warranty Coverage
Enjoy 12 months of factory warranty for defects in materials or workmanship.
Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
