Bently Nevada | 330173-00-06-10-02-00 3300 5mm Proximity Probes

Bently Nevada 3300 Series 5mm Proximity Probe

Precision vibration monitoring sensor with robust stainless steel construction. Made in USA for industrial machinery protection.

Product Details

Manufacturer: Bently Nevada
Full Model: 330173-00-06-10-02-00
Probe Type: 5mm diameter, M8×1 thread
Material: AISI 304 SST case, PPS tip
Origin: U.S.A. (COO available)

Key Specifications

Measurement Range: 50 mils (1.27mm) gap
Accuracy: ±2mV/V sensitivity
Output: -17.5 to -26 VDC, 50Ω resistance
Temp Range: -35°C to +177°C (-31°F to +351°F)

Technical Features

• Cable: 1.0m FEP-insulated triaxial (75Ω)
• Connector: Miniature coaxial ClickLoc
• Resistance: 7.59±0.50Ω at 1m length
• Torque: 5.1 N·m recommended (7.3 N·m max)
• Bend Radius: 25.4mm minimum
• Tensile Strength: 222N (50 lbf)

Installation Guide

1. Mount with M8×1 threading
2. Maintain 1.27mm gap to target surface
3. Apply 5.1 N·m torque to housing
4. Keep bend radius >25.4mm
5. Use AISI 4140 steel targets

Compatibility

Works with Bently Nevada 3300/3500 monitoring systems. Compatible with industrial turbines, compressors, and rotating machinery.

Certifications

No agency approvals required (as per model suffix 00)

What’s Included

• Probe assembly (60mm length)
• 1.0 meter cable
• ClickLoc connector
• Installation manual

Warranty & Support

1-year manufacturer warranty against defects. Technical support available for installation and troubleshooting.

Real-World Applications

Gas Turbine Monitoring: Detects blade vibration in power plants
Compressor Protection: Measures shaft displacement in refineries
Hydroelectric Plants: Monitors bearing wear in water turbines

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
