Bently Nevada 5mm Armored Vibration Probe
Model: 330172-05-63-05-02-CN
Made in USA • 6.3″ steel body • 0.5m armored cable • China approvals
Key Features
- 5mm vibration sensor
- 6.3″ stainless steel case
- 0.5″ smooth section
- Armored 0.5m cable
- China certified (CN)
Technical Specs
- Power: -17.5V to -26V
- Thread: 1/4-28 UNF
- Temp: -35°C to +177°C
- Weight: 0.32kg
- ClickLoc connector
Model Number Breakdown
| Code | Meaning | Value |
|---|---|---|
| 330172 | Base Model | 5mm Armored Probe |
| 05 | Unthreaded Length | 0.5 inches |
| 63 | Case Length | 6.3 inches |
| 05 | Cable Length | 0.5 meters |
| 02 | Connector | Standard ClickLoc |
| CN | Approvals | China Certified |
Installation Guide
Drilling
- Use #3 drill bit
- 1/4-28 UNF threads
Mounting
- Tighten to 45 in-lb
- Max 0.375″ thread depth
- Don’t over-tighten
What’s Included
- 1 vibration probe
- 0.5m armored cable
- ClickLoc connector
Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
