Bently Nevada 330130-085-11-00 3300 XL Armored FluidLoc Extension Cable

Description

Great for industrial sensing systems, this 3300 XL extension cable from Bently Nevada is strong and accurate. It works well with 3300-series probes. The armored FluidLoc cable stops liquid leaks. It also comes with silicone tape for connector protection (but not good for turbine oil areas).

Model Suffix Meanings

330130: Main code for 3300 XL extension cables.
085: Cable length – 8.5 meters (27.9 feet).
11: Cable style – Armored FluidLoc (stops oil/liquid leaks).
00: No extra approvals needed.

Technical Details

Brand: Bently Nevada
Model: 330130-085-11-00
Length: 8.5m (27.9ft)
Weight: 0.618kg (armored)
Capacitance: 69.9pF per meter (21.3pF per foot) – typical.
DC Resistance:
Center wire (RCORE): 1.87Ω (±0.28) for 8.5m.
Outer wire (RJACKET): 0.56Ω (±0.11) for 8.5m.
Power Need: -17.5Vdc to -26Vdc (no barriers); -23Vdc to -26Vdc (with barriers).
Supply Sensitivity: Output changes less than 2mV per volt input change.
Output Resistance: 50Ω.
Linear Range: 2mm (80 mils) (0.25-2.3mm / 10-90 mils).

Works With

3300 5mm proximity probes
3300 8mm proximity probes
3300 XL 8mm proximity probes

Install Tips

Use 3-wire shielded triad cable (0.2-1.5mm² / 16-24 AWG) for field wiring.
Max field wire length: 305m (1,000ft). Longer wires may lower high-frequency signal quality.
Don’t use silicone tape if the probe-extension connection touches turbine oil.

Top Features

Armored build for extra strength.
FluidLoc cable stops liquid leaks.
CableLoc tech (330N/75lbf pull strength) holds cable and tip tight.
TipLoc molding makes probe tip and body stronger.Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
