Bently Nevada 330130-045-01-00 Armored Extension Cable
What the Model Numbers Mean
- 330130 → Base series: 3300XL system extension cables
- -045 → Length: 4.5 meters (14.8 feet)
- -01 → Cable type: Armored (stainless steel for strength)
- -00 → Approvals: No special certs needed (general use)
Key Details
- Brand: Bently Nevada (made in U.S.A.)
- Model: 330130-045-01-00
- Type: Armored extension cable (for 3300XL systems)
- Length: 4.5m (14.8ft) – good for short/medium setups
- Weight: 103g per meter (1.5oz/ft) – total ~0.46kg
- Capacitance: 69.9pF/m (21.3pF/ft) – keeps signals steady
- Wire resistance:
- Center wire: 1.0±0.15Ω (4.5m) – clear signal
- Outer wire: 0.3±0.06Ω (4.5m) – strong shielding
- Power: Needs -17.5Vdc to -26Vdc (no barriers) or -23Vdc to -26Vdc (with barriers). Max current: 12mA.
- Output resistance: 50Ω – matches industry standards
- Linear range: 2mm (80 mils) – works from 0.25mm to 2.3mm (10-90 mils)
Design & Compatibility
- Connector: Gold-plated ClickLoc – resists rust, tight connection
- Comes with: Silicone tape (use instead of protectors; avoid in turbine oil)
- Works with: 3300XL 8mm probes, cables, and sensors (no extra setup)
- Humidity: <3% change after 56 days at 93% humidity (IEC 68-2-3)
Install Tips
- Use 0.2-1.5mm² (16-24 AWG) shielded triad wires
- Max wire length: 305m (1,000ft) – check signal loss for long runs
- Don’t use silicone tape where oil touches the connection
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
