Bently Nevada 330103-00-04-10-01-00 3300 XL 8mm Proximity Probe

1. What It Does

A small, durable sensor for measuring machine vibration in factories or workshops. Made by Bently Nevada, it’s built to work reliably in tight spaces with its 1-meter design.

2. Model Number: Piece by Piece

Let’s take apart 330103-00-04-10-01-00:

330103: Base 8mm probe (M10x1 thread, no armor)
00: No extra unthreaded part (0mm)
04: Case length (40mm)
10: Total probe length (1.0m / 3.3ft)
01: Connector type (small ClickLoc with protector + standard cable)
00: No special safety approvals needed

3. Key Tech Details

Measure range: 2mm (80 mils) – works from 0.25mm (10 mils) to 2.3mm (90 mils)
Resistance: 7.59Ω ±0.50Ω (for 1m length)
Temp range: Works from -52°C to +177°C (-62°F to +350°F). Tip handles up to +218°C (+425°F).
Cable max: 305m (1,000ft) between probe and monitor

4. What’s Inside

Tip: PPS plastic (strong, won’t melt easily)
Case: AISI 303/304 stainless steel (tough, won’t rust)
Seal: Viton O-ring (keeps pressure in place between tip and case)
Weight: 323g/m (11.4oz) – light but strong

5. Safe to Use

Explosive areas: Safe in Class I Zone 0 (Groups A-D) and Class II (Groups E-G) with proper setup.
Non-explosive areas: Safe in Class I Zone 2 (Division 2, Groups A-D).

6. How to Install

Use 3-wire shielded cable (0.2-1.5mm² / 16-24 AWG).
Tin the wires for better connections.
Keep it above -34°C (-30°F) to avoid seal damage.

7. Works With

Pairs with 3300 XL Proximitor Sensors for full setup.

8. What’s in the Box

1x 330103-00-04-10-01-00 proximity probe unit.
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
