Bently Nevada | 330103-00-03-10-12-CN | 8 mm Probes

Bently Nevada 3300 XL 8 mm Proximity Probe – Model 330103-00-03-10-12-CN

Overview

Designed for precise industrial vibration monitoring, this 3300 XL 8 mm Proximity Probe from Bently Nevada combines a durable PPS tip with a stainless steel body. Built to withstand extreme temperatures and high humidity, it ensures reliable performance in tough environments.

Model Code Decoded (330103-00-03-10-12-CN)

330103: Base 8mm probe (M10x1 thread, no armor)
00: Unthreaded length (0mm)
03: Case length (30mm)
10: Total cable length (1.0m/3.3ft)
12: Connector (Miniature coaxial ClickLoc + FluidLoc cable)
CN: Country-specific approval

Top Specifications

Linear Range: 2mm (80 mils) (0.25-2.3mm/10-90 mils)
DC Resistance: 7.59 ± 0.50Ω (1.0m cable)
Operating Temp (Standard): -52°C to +177°C (-62°F to +350°F)
Extended Tip Temp: -52°C to +218°C (-62°F to +425°F)
Materials: PPS tip + AISI 303/304 stainless steel case
Humidity Resistance: <3% signal change at 93% humidity (up to 56 days)

Installation & Use

Wiring: Use 0.2-1.5mm² (16-24 AWG) wires. Best with 3-conductor shielded triad (tinned).
Max Distance: 305m (1,000ft) between probe and 3300 XL Proximitor Sensor. Longer wires may reduce high-frequency signals.
Gap Setting: -9 Vdc (≈1.27mm/50 mils) for radial vibration.

Safety Ratings

Intrinsically Safe (ia): Class I Zone 0, AEx/Ex ia IIC T5…T1 Ga
Nonincendive (nA/ec): Class I Zone 2, AEx/Ex nA/ec IIC T5…T1 Gc
Additional Approval: Country-specific certification (CN)

What’s in the Box

1x 3300 XL 8mm Probe (M10x1 thread, no armor)
1x 1.0m FluidLoc cable with Miniature coaxial ClickLoc connector

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
