Bently Nevada 3300 XL 8mm Proximity Probe
Product Overview
The 330102-00-24-10-02-00 is an industrial-grade vibration sensor with:
- 8mm sensing tip for precise measurements
- Stainless steel body for durability
- 1 meter cable with ClickLoc connector
Key Specifications
Model: 330102-00-24-10-02-00
Size: 8mm diameter
Range: 0.25-2.3mm (10-90 mils)
Output: -1 to -17 Vdc
Temperature: -52°C to +177°C
Weight: 323 g/m
Model Number Breakdown
| Code | Meaning | Your Selection |
| 330102 | Base model | 8mm probe |
| 00 | Unthreaded length | 0 inch |
| 24 | Case length | 2.4 inch |
| 10 | Cable length | 1.0 meter |
| 02 | Connector type | ClickLoc |
| 00 | Approvals | Standard |
Installation Guide
- Thread size: 3/8-24 UNF
- Max thread engagement: 0.563 inch
- Optimal gap setting: 1.27mm (50 mils)
- Min operating temp: -34°C to protect seals
Compatible With
Works with all 3300 XL 5-meter Proximitor systems
Package Includes
- 1 × 8mm proximity probe
- 1 × 1.0 meter cable
- ClickLoc connector
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
