Bently Nevada 3300 XL 8mm Vibration Probe – High-Performance Monitoring Solution

Description

The Bently Nevada 330101-00-27-15-02-00 is a rugged 8mm proximity probe designed for precise vibration and position monitoring in industrial machinery. Featuring a 3/8-24 UNF thread and PPS plastic tip, it offers superior durability with patented TipLoc and CableLoc technology for enhanced pull strength (75 lbf). Ideal for harsh environments, it operates in temperatures from -52°C to +177°C and includes a miniature coaxial ClickLoc connector.

Technical Data

• Brand: Bently Nevada
• Model: 3300 XL 8mm Probe | P/N: 330101-00-27-15-02-00
• Suffix Breakdown:

• Linear Range: 2mm (80 mils), starting at 0.25mm from target
• Output Signal: 7.87 V/mm ±5% (5m system)
• Resistance: 7.73Ω ±0.50 (1.5m cable)
• Material: PPS tip, AISI 303/304 stainless steel case
• Weight: 323 g/m (11.4 oz)

Installation & Compatibility

Works with 3300 XL monitors and supports 305m (1000ft) field wiring. Use shielded triad cable (16-24 AWG). Optimal gap setting: 1.27mm (50 mils) for radial vibration.

Certifications & Packaging

Complies with IEC 68-2-3 humidity standards. Includes probe with ClickLoc connector. Made in USA.

Real-World Applications

Used in turbines, compressors, and motors for predictive maintenance. The 8mm design resists physical damage in high-vibration zones.

Shipping: FedEx, UPS, or DHL express worldwide.

Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
