Analog Output Module Schneider Electric 140AMM09000

Schneider Electric Modicon Quantum Analog I/O Module

The Schneider Electric 140AMM09000 is a high-performance analog input and output module. It is designed for the reliable Modicon Quantum automation platform. This module provides precise signal conversion for industrial control.

Core Specifications & Technical Details

• Brand: Schneider Electric
• Series: Modicon Quantum
• Model: 140AMM09000
• Product Type: Analog Input/Output Module
• Total Channels: 6 channels (4 Input / 2 Output)

Analog Input Specifications

• The module offers four highly configurable analog input channels.
• It accepts a broad range of voltage and current signals.
• Supported types include ±10V, 0-10V, 4-20mA, and ±20mA.
• The input resolution is up to 16 bits for voltage signals.
• A built-in 21 Hz low-pass filter helps reduce signal noise.
• Input impedance is high: >10 MΩ for voltage and 250 Ω for current.
• The absolute accuracy error is typically ±0.03% at 25°C (77°F).
• It features excellent >80 dB common mode rejection at 50/60 Hz.

Analog Output Specifications

• This unit integrates two independent analog output channels.
• The standard output range is the industrial 4…20 mA current loop.
• Output resolution is a precise 12 bits for accurate control.
• The output update is fast with a 15 ms cycle time.
• The settling time is a quick 900 µs to within ±0.1% of final value.
• The loop voltage supply can be 7…30 V DC for standard operation.

Environmental Ratings & Safety

• The operating air temperature range is 0 to 60°C (32 to 140°F).
• It can withstand storage from -40 to 85°C (-40 to 185°F).
• This module works at altitudes up to 5000 meters (16404 ft).
• It handles up to 95% relative humidity without condensation.
• Isolation between channels and the bus is 500 V AC for 1 minute.
• It has strong resistance to electromagnetic interference fields.

Installation, Diagnostics & Packaging

• The module uses a standard format for easy installation in a Quantum rack.
• LED indicators show bus activity, faults, and individual channel status.
• Addressing requires 5 input words and 2 output words in the PLC memory.
• The bus current requirement is 350 mA from the Quantum backplane.
• Package weight is approximately 461 grams (16.3 oz).
• Our packing list includes the brand new and original 140AMM09000 module.
• We ship quickly worldwide via DHL, FedEx, and UPS courier services.

Frequently Asked Questions (FAQ)

• Q: Is the 140AMM09000 module brand new and original?
  A: Yes, we supply only 100% new and original Schneider Electric products.
• Q: Do you have this item in stock? How soon do you ship?
  A: We typically have stock available and process orders for shipping within 5 business days.
• Q: What shipping methods do you use?
  A: We use common global carriers like DHL, FedEx, and UPS for reliable delivery.
• Q: What input signal types does it support?
  A: It supports many types including ±10V, 0-10V, 4-20mA, and 0-20mA, both unipolar and bipolar.
• Q: What is the isolation rating for safety?
  A: Channels are isolated from the bus at 500V AC for 1 minute, ensuring system protection.
