A06B-6114-H105 FANUC Servo Amplifier Module | 19A 200-240VAC

FANUC A06B-6114-H105 Servo Amplifier Module Overview

Technical Specifications

• Manufacturer: FANUC
• Product Line: A06B
• Model: A06B-6114-H105
• Product Type: Servo Amplifier Module
• Input Voltage: 283–339 VDC
• Input Frequency: 50/60 Hz
• Rated Input Power: 5.5 kW
• Output Voltage: 200–240 VAC
• Rated Output Current: 19A
• Output Frequency Range: 0.1 – 800 Hz
• Min. Ambient Operating Temperature: 0°C
• Max. Ambient Operating Temperature: 55°C
• Ambient Humidity: 90% RH or less (No condensation)
• Weight: 4.99 kg (11.00 lbs.)

Frequently Asked Questions (FAQ)

• Is this servo amplifier brand new and original?
  Yes, we supply a brand new and original FANUC A06B-6114-H105. It comes directly from authorized sources with full traceability.
• What is the current stock availability?
  We have this servo amplifier module in stock. Orders ship within 5 business days after payment confirmation.
• Which shipping carriers do you use?
  We ship using DHL, FedEx, and UPS. We select the best carrier based on your location and delivery requirements.
• What output frequency range does this module support?
  The A06B-6114-H105 supports output frequencies from 0.1 to 800 Hz. This wide range accommodates various motor speed control applications.
• Can this unit operate in high-humidity environments?
  Yes, it functions in humidity up to 90% RH without condensation. Ensure the installation location remains free from moisture buildup.
• What is the return policy?
  We accept returns within 30 days of delivery. The product must remain in original, unused condition.
