Bently Nevada 3300 XL 8mm Proximity Probe
Model 330103-00-04-50-12-00
Key Features
- ✔ 8mm vibration measurement
- ✔ Compact 40mm stainless steel housing
- ✔ 5m FluidLoc oil-resistant cable
- ✔ Wide temperature range (-52°C to +177°C)
- ✔ M10×1 threaded mounting
Model Number Breakdown
330103 ─── Base 8mm Probe ├─ 00 ─── 0mm unthreaded length ├─ 04 ─── 40mm case length ├─ 50 ─── 5.0 meter cable ├─ 12 ─── FluidLoc/ClickLoc connector └─ 00 ─── No agency approvals
Technical Specifications
| Measurement Range | 0.25-2.3mm (10-90 mils) |
| Output Signal | -1 to -17 Vdc |
| Resistance | 8.73Ω ±0.50 |
| Thread Spec | M10×1 (15mm max) |
| Weight | 323 g/m |
| Sealing | Viton® O-ring |
Installation
- Mount with M10×1 thread
- Set gap to 1.27mm (50 mils)
- Use shielded cable (16-24 AWG)
- Max cable length: 305m
Applications
- Industrial machinery
- Non-hazardous areas
- Equipment condition monitoring
- Predictive maintenance
Package Contents
- 1 × 8mm Proximity Probe
- 5m FluidLoc Cable
- ClickLoc Connector
Download PDF file here:3300 XL 8 mm Proximity Transducer System Datasheet
