5mm Proximity Probes – 330171-00-12-10-02-CN | Bently Nevada

Industrial-Grade Vibration Sensing Solution

Precision Measurement Probe

Bently Nevada’s 330171-00-12-10-02-CN vibration probe delivers accurate machinery monitoring with its 5mm sensing tip. Featuring a 1/4-28 UNF threaded stainless steel case and 1.0 meter cable, this U.S.-made sensor withstands industrial environments from -35°C to +177°C (-31°F to +351°F).

Technical Specifications

Brand: Bently Nevada

Full Model: 330171-00-12-10-02-CN

Cable Length: 1.0m (3.3 ft)

Power Requirements: -17.5 to -26 VDC

Current Draw: 12mA max

Output Resistance: 50Ω

Probe Resistance: 7.59±0.50Ω

Case Material: AISI 304 Stainless Steel

Tip Material: PPS polymer

Weight: 0.323kg

Robust Construction

Designed for durability with 222N (50 lbf) tensile strength connections. Features a miniature coaxial ClickLoc connector and withstands installation torque up to 7.3 N·m (65 in·lb) on case threads. Maintain 25.4mm (1.0in) minimum bend radius during installation.

Installation Notes

Use #3 or larger tap drill for mounting holes. Limit thread engagement to 0.375 inches maximum. Avoid temperatures below -34°C (-30°F) to prevent seal damage. Maintain 1.27mm gap to target surface.

Compatibility

Works with Bently Nevada 3300 monitoring systems. Features country-specific CN region approvals. Optional Certificate of Origin available.

Package Includes

Vibration probe with 1.0m cable, connector protector, and installation documentation

Quality Assurance

Backed by 1-year manufacturer warranty against defects

Industrial Applications

• Turbine vibration monitoring
• Pump performance tracking
• Compressor health analysis
• Generator protection systems

Download PDF file here:3300 5 mm Transducer System Datasheet – 172036
