330881-28-00-095-05-01 | Bently Nevada Proximity Transducer

Bently Nevada PROXPAC XL Proximity Transducer (Model: 330881-28-00-095-05-01)

What It Is

A tough sensor for measuring proximity. Made by Bently Nevada, it works well in rough conditions. Durable design with UV protection and IP66 rating.

Model Numbers Explained

28: 3300 XL 8 mm probe with many approvals
00: No extra standoff adapter
095: Probe goes in 95mm deep
05: Includes 1 PG21 to PG11 reducer + 2 plugs
01: M24 X 3 mounting thread

Key Features

Brand: Bently Nevada
Type: PROXPAC XL Proximity Transducer
Range: 2 mm (80 mils) linear (0.25-2.3 mm / 10-90 mils)
Accuracy: ±0.025mm (±1 mil) (0°C-45°C)
Output: -1Vdc to -17Vdc; 50Ω resistance
Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
Temp Range: Probe works from -51°C to +177°C (-60°F to +350°F)

How to Install

Tighten: Retaining nut (29.5 N·m), probe sleeve locknut (39.3 N·m)
Wires: Use 3-conductor shielded triax cable (0.2-1.5 mm²). Max 305m (1,000ft) from sensor to monitor.

What It Works With

Smallest Target: 15.2mm (0.6in) flat target
Smallest Shaft: 50.8mm (2.0in)

Certifications

IP66 (BASEEFA T07/0709)
Passes 4J impacts at -39°C/115°C (BASEEFA) and 7J at room temp (CSA)

What’s in the Box

3300 XL 8 mm probe
1m 75Ω FEP-insulated triaxial cable
1 PG21 to PG11 reducer
2 plugs

Download PDF file here:PROXPAC XL Proximity Transducer
