330706-005-046-10-02-00 | Bently Nevada Reverse Mount Probe

Bently Nevada 3300 XL 11mm Reverse Mount Probe – Easy Machine Check Tool

Quick Facts at a Glance

Length: 1.0m (3.3ft) – fits tight spaces
Temp Range: -52°C to 177°C (-62°F to 351°F) – works in extreme cold/hot
Weight: 0.07kg – light for easy handling
Key Use: Checks shaft vibration, position, speed in factories

Model Code Breakdown (330706-005-046-10-02-00)

005: Basic design style
046: Standard probe tip shape
10: 1.0m total length (only for 1m sensors)
02: Small ClickLoc™ connector (easy to attach)
00: No extra safety approvals needed

What It’s Built From

Tip: PPS plastic – tough against heat/chemicals
Body: AISI 304 stainless steel – no rust, lasts long
Cable: 75Ω triaxial, FEP-insulated – works for 1m, 5m, 9m lengths

Tech Numbers You Need

DC Resistance: 5.9 ± 0.5 ohms (1.0m length) – stable signal
Max Torque: 0.565 N•m (5 in•lb) – don’t over-tighten!
Min Bend Radius: 25.4mm (1.0in) – avoid kinking the cable
Seal: Viton® O-ring – stops pressure leaks (ask Bently for tests)

Install Tips

Screw Type: M10 x 1 – quick to fit
Best Tightness: Finger tight first, then max 0.565 N•m
Cold Warning: Below -34°C (-30°F) may damage the seal – use extra care

What It Works With

Only for Bently Nevada 1m Proximitor Sensors (model 3300/16-1m). Using other lengths may cause bad data.

Box Includes

1x 3300 XL 11mm probe (1.0m)
1x Miniature ClickLoc™ connector
1x simple setup guide (English/French)

Warranty

1-year coverage for factory-made issues. No cover if damaged by wrong use.

Real-World Example

A Chicago food plant uses this probe to check mixer shafts. With its 1.0m length, it fits small spaces, and the -52°C rating keeps data right in cold storage areas.
Download PDF file here:3300 XL 11 mm Proximity Transducer System Datasheet
