330104-10-16-10-12-00 | Bently Nevada | 8 mm Probes With Armor

Bently Nevada 330104-10-16-10-12-00 3300 XL 8mm Proximity Probe

Description

A durable sensor for industrial machine checks. Made by Bently Nevada, it has a strong stainless steel case, a PPS tip, and a Viton O-ring to seal pressure. Good for reliable machine monitoring.

Technical Data

Brand: Bently Nevada
Model: 330104-10-16-10-12-00 (3300 XL 8mm series)

Model Suffix Breakdown:

10: Unthreaded length (100mm)
16: Case length (160mm)
10: Total cable length (1.0m / 3.3ft)
12: Connector type (Mini ClickLoc, FluidLoc cable)
00: No country-specific approvals needed
Key Specs:

Probe resistance: 7.59 ± 0.50Ω (1.0m length)
Input voltage: -17.5Vdc to -26Vdc (non-incendive), -23Vdc to -26Vdc (with barriers)
Output resistance: 50Ω
Sensitivity: <2mV output change per 1V input
Temp range: 18°C-27°C (64°F-80°F)
Max altitude: 2000m

Install Tips

Use non-incendive circuits (follow drawing 140979). Set gap at 1.27mm (50 mils) with AISI 4140 steel targets for best use.

Works With

Fits 3300-series 5mm probes, 3300 XL 8mm probes, and matching extension cables.

Safety Ratings

Intrinsically safe (ia): Class I Zone 0, Groups A/B/C/D
Non-incendive (nA/ec): Class I Zone 2, Division 2
Temp ratings: T1 (-55°C to +232°C) up to T5 (-55°C to +40°C)

What’s Included

1x 3300 XL 8mm Proximity Probe
1x User guide
DownloadPDF fie here:3300 XL 8 mm Proximity Transducer System Datasheet</a
