Bently Nevada 330104-00-02-15-01-00 3300 XL 8mm Proximity Probe

Description

A tough sensor for industrial machine checks. Made by Bently Nevada, it has a strong stainless steel case, a PPS tip, and a Viton O-ring to seal pressure. Good for reliable machine monitoring.

Technical Data

Brand: Bently Nevada
Model: 330104-00-02-15-01-00 (3300 XL 8mm series)

Model Suffix Breakdown:

00: Unthreaded length (0mm)
02: Case length (20mm)
15: Total cable length (1.5m / 4.9ft)
01: Connector type (Mini ClickLoc with protector, standard cable)
00: No country-specific approvals needed
Key Specs:

Probe resistance: 7.73 ± 0.50Ω (1.5m length)
Input voltage: -17.5Vdc to -26Vdc (non-incendive), -23Vdc to -26Vdc (with barriers)
Output resistance: 50Ω
Sensitivity: <2mV output change per 1V input
Temp range: 18°C-27°C (64°F-80°F)
Max altitude: 2000m

Install Tips

Use non-incendive circuits (follow drawing 140979). Set gap at 1.27mm (50 mils) with AISI 4140 steel targets for best use.

Works With

Fits 3300-series 5mm probes, 3300 XL 8mm probes, and matching extension cables.

Safety Ratings

Intrinsically safe (ia): Class I Zone 0, Groups A/B/C/D
Non-incendive (nA/ec): Class I Zone 2, Division 2
Temp ratings: T1 (-55°C to +232°C) up to T5 (-55°C to +40°C)

What’s Included

1x 3300 XL 8mm Proximity Probe
1x User guide
Download PDF fie here:3300 XL 8 mm Proximity Transducer System Datasheet</a
